2. Configure Device B:

# Enable DLDP globally.

<DeviceB> system-view

[DeviceB] dldp global enable

# Configure Ten-GigabitEthernet 1/0/1 to operate in full duplex mode and at 10000 Mbps, and

enable DLDP on it.

[DeviceB] interface ten-gigabitethernet 1/0/1

[DeviceB-Ten-GigabitEthernet1/0/1] duplex full

[DeviceB-Ten-GigabitEthernet1/0/1] speed 10000

[DeviceB-Ten-GigabitEthernet1/0/1] dldp enable

[DeviceB-Ten-GigabitEthernet1/0/1] quit

# Configure Ten-GigabitEthernet 1/0/2 to operate in full duplex mode and at 10000 Mbps, and

enable DLDP on it.

[DeviceB] interface ten-gigabitethernet 1/0/2

[DeviceB-Ten-GigabitEthernet1/0/2] duplex full

[DeviceB-Ten-GigabitEthernet1/0/2] speed 10000

[DeviceB-Ten-GigabitEthernet1/0/2] dldp enable

[DeviceB-Ten-GigabitEthernet1/0/2] quit

# Set the port shutdown mode to manual.

[DeviceB] dldp unidirectional-shutdown manual

3. Verify the configuration:

After the configurations are complete, you can use the display dldp command to display the

DLDP configuration globally and on ports.

# Display the DLDP configuration globally and on all the DLDP-enabled ports of Device A.

[DeviceA] display dldp

DLDP global status: Enabled

DLDP advertisement interval: 5s

DLDP authentication-mode: None

DLDP unidirectional-shutdown mode: Manual

DLDP delaydown-timer value: 1s

Number of enabled ports: 2

Interface Ten-GigabitEthernet1/0/1

DLDP port state: Bidirectional

Number of the port’s neighbors: 1

Neighbor MAC address: 0023-8956-3600

Neighbor port index: 1

Neighbor state: Confirmed

Neighbor aged time: 11s

Interface Ten-GigabitEthernet1/0/2

DLDP port state: Bidirectional

Number of the port’s neighbors: 1

Neighbor MAC address: 0023-8956-3600

Neighbor port index: 2

Neighbor state: Confirmed

Neighbor aged time: 12s
