hpmont HD30 Series User Manual

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―88― HD30 Series Inverters User Manual
No. Name Description Range
【
factory setting
】
F13.23 Torque boost of motor 2 0.0
－
30.0
【
45kW and below inverter: 2.0%
】
【
55
－
132kW inverter: 1.0%
】
【
160kW and above inverter: 0.5%
】
F13.24
Cut-off point used for manual torque boost of motor 2
0.0－50.0 (F13.04)【30.0%】
F13.25 Slip compensation gain of motor 2 0.0
－
300.0
【
100.0%
】
F13.26
Slip compensation filter time of motor 2
0.01－10.00【0.10s】
F13.27 Slip compensation limitation of motor 2 0.0
－
250.0
【
200.0%
】
F13.28
Compensation constant of motor 2
0.1－25.0【2.0s】
F13.29 Reserved
F13.30
AVR (automatic voltage regulation) function of motor 2
0－2【1】
F13.31 Oscillation-suppression mode of motor 2 0,1
【
0
】
F13.32
Oscillation-suppression coefficient of motor 2
0－200【50】
F13.33 Reserved
F13.34
Reserved
F13.35 Speed control proportional gain 1 of motor 2 0.1
－
200.0
【
20.0
】
F13.36
Speed control integral time 1 of motor 2
0.00－10.00【0.20s】
F13.37 Speed control proportional gain 2 of motor 2 0.1
－
200.0
【
20.0
】
F13.38
Speed control integral time 2 of motor 2
0.00－10.00【0.20s】
F13.39 Speed-loop PI switching frequency 1 of motor 2 0.00
－
50.00
【
10.00Hz
】
F13.40
Speed-loop PI switching frequency 2 of motor 2
0.00－50.00【15.00Hz】
F13.41 Speed-loop integral limitation of motor 2 0.0
－
200.0 (F13.03)
【
180.0%
】
F13.42
Speed-loop differential time of motor 2
0.00－1.00【0.00s】
F13.43 Speed-loop output filter time of motor 2 0.000
－
1.000
【
0.020s
】
F13.44
Reserved
F13.45 Reserved
F13.46
Motor torque limitation when motor 2 is forward
0.0
－
200.0 (F13.03)
【
180.0%
】
F13.47 Motor torque limitation when motor 2 is reverse
F13.48
Recreated torque limitation when motor 2 is forward
F13.49 Recreated torque limitation when motor 2 is reverse
F13.50
Reserved
F13.51 Reserved
F13.52
Reserved
6.2.15 Group F14 Reserved
