Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―54― HD30 Series Inverters User Manual
6.1 Group d: Display Parameters
Group d is status display parameters. The users can directly check the status parameters by
checking the function code of Group d.
6.1.1 Group d00 Status Display Parameters
No. Name Description Range
factory setting
d00.00 Series of the inverter
Actual value
Display the series of the inverter.
d00.01 Software version of the control board
Actual value
Display the software version of the control board.
d00.02 Reserved
Special software version of the control board
Display the special software version of the control board.
d00.05 Software version of the display panel
Actual value
Display the software version of the display panel.
d00.06 Customized series No.
Actual value
Display the customized series No.
d00.07 Motor and control mode
Actual value
Display the current motor and the control mode.
Units: Display the current driving motor
• 0: Motor 1.
• 1: Motor 2.
Tens: Control mode
• 0: V/f contorl without PG.
• 1: Reserved.
• 2: Vector control without PG.
d00.08 Rated current of the inverter
Actual value
Display the rated current of the inverter.
d00.09 Extension function of the inverter
Actual value
Display the extension function of the inverter.
0: Standard inverter.
