6.2 Group F: General Function Parameters
6.2.1 Group F00 Basic Parameters
No. Name Description Range
【
factory setting
】
F00.00 Reserved
F00.01
Motor 1 control mode selection
0－2【0】
0: V/f control without PG. Constant voltage/frequency ratio control.
• It is specially applicable for occasions when one inverter drives more than one motors to
achieve proper efficiency.
• When select V/f control, please properly set the V/f control parameter of Group F09 or Group
F13 to achieve proper efficiency.
1: Reserved.
2: Vector control without PG. Sensorless vector control.
• It is applicable for application with high requirement on inverter performance and torque.
• At first, it must perform motor parameter auto-tuning. And then adjust the settings of F08.00－
F08.04 according to the nameplate of the motor. Start the motor parameter auto-tuning function
and properly set Group F10 parameters, so as to achieve excellent vector control efficiency.
F00.02
Inverter type setting
0,1【0】
0: G type, to drive heavy and general motor.
1: P type, to drive pump and fan.
F00.03
Motor selection
0,1【0】
0: Motor 1.
1: Motor 2.
Note: It can preset two group motor parameters. At stop they can shift even without input
parameters when they are respectively driving two motors.
F00.04
HD30 general extension option selection
0－3【0】
0: Option is invalid.
1: HD30-EIO is valid.
2: Reserved.
3: HD30-PIO is valid.
Note: The extension function can be used with the corresponding option.
F00.05
HD30 extension application function
0,1【0】
0: No extension application.
F00.06
Inverter maximum output frequency
50.00－400.00【50.00Hz】
It defines the highest frequency that the inverter is allowed to output.
• It should be careful to set reasonable parameters according to the nameplate of the motor and the
actual operating conditions.
F00.07
Upper limit of operation frequency setting source
0－2【0】
It defines the highest frequency that the user is set to operate, and select different setting sources to
set the upper limit frequency by F00.07.
0: Digital setting. Set the upper limit frequency by F00.08.
1: Analogue input AI setting. See Group F16.
2: Terminal pulse setting. F16.17 sets the max. pulse input frequency according to F00.06 (inverter
max. output frequency).
