hpmont HD30 Series User Manual

Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―74― HD30 Series Inverters User Manual
6.2.7 Group F06 MS SPEED and Simple PLC
Simple PLC function enables the inverter to change its running frequency and direction
automatically according to PLC parameter settings.
No. Name Description Range
【
factory setting
】
F06.00
Multi-step frequency command 1
F00.09－upper limit【3.00Hz】
F06.01 Multi-step frequency command 2 F00.09
－
upper limit
【
6.00Hz
】
F06.02
Multi-step frequency command 3
F00.09－upper limit【9.00Hz】
F06.03 Multi-step frequency command 4 F00.09
－
upper limit
【
12.00Hz
】
F06.04
Multi-step frequency command 5
F00.09－upper limit【15.00Hz】
F06.05 Multi-step frequency command 6 F00.09
－
upper limit
【
18.00Hz
】
F06.06
Multi-step frequency command 7
F00.09－upper limit【21.00Hz】
F06.07 Multi-step frequency command 8 F00.09
－
upper limit
【
24.00Hz
】
F06.08
Multi-step frequency command 9
F00.09－upper limit【27.00Hz】
F06.09 Multi-step frequency command 10 F00.09
－
upper limit
【
30.00Hz
】
F06.10
Multi-step frequency command 11
F00.09－upper limit【33.00Hz】
F06.11 Multi-step frequency command 12 F00.09
－
upper limit
【
36.00Hz
】
F06.12
Multi-step frequency command 13
F00.09－upper limit【39.00Hz】
F06.13 Multi-step frequency command 14 F00.09
－
upper limit
【
42.00Hz
】
F06.14
Multi-step frequency command 15
F00.09－upper limit【45.00Hz】
They define the initial value of each step speed in multi-step speed mode and PLC operation mode.
F06.15
Simple PLC control selection
0,1【0】
0: No PLC operation.
1: Enabling PLC operation. It need reset the value of F06.16－F06.46 according to actual operation.
