hpmont HD30 Series User Manual

Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd
―6― HD30 Series Inverters User Manual
2.3 Specifications
Item Specification
Electrical
Rated voltage and
frequency
Single/three-phase: 200－240V, 50/60Hz
Three-phase: 380－460V, 50/60Hz
Accuracy
Voltage: fluctuating within ± 10%, imbalance rate < 3%
Frequency: ± 5%
Output voltage 0－input voltage
Output frequency 0－400.00Hz
Performance
Maximum current
150% rated output current for 2 minutes
180% rated output current for 10 seconds
Control mode Sensorless vector control; V/f control
Operation command
channel
Panel; terminals; communication
Speed setting mode Digital setting, analogue setting, SCI communication setting
Speed setting resulotion
Digital setting: 0.01Hz
Analogue setting: 0.1% × max-frequency
Speed control accuracy Sensorless vector control: ± 0.5%
Speed control range Sensorless vector control: 1:100
Torque control response Sensorless vector control: < 200ms
Start torque Sensorless vector control: 180% rated-torque /0.5Hz
Torque control accuracy ±5%
Characteristic
User-definable menu Total 16 user-definable maps, user can edit
Multi-group parameter
upload and download
function
To achive 2 group parameters uploading to display panel of backup
function
Programmable I/O
interface
Input interface programmable is up to 53 functions
Output interface pragrammable is up to 38 functions
Process PID adjustment Internal process PID module
Simple PLC
To achive time and multi-frequency output with internal simple PLC
module
Wobble operation Internal wobble operation module
Length control Internal length control module
Compatible
multi-communication
protocol
Inverter built-in MODBUS communication protocol.
Available options:
PROFIBUS bus module, compatible with PROFIBUS protocol;
DeviceNet bus module, compatible with DeviceNet protocol;
CAN bus module, compatible with CAN communication protocol;
