Shenzhen Hpmont Technology Co., Ltd Chapter 9 Options
HD30 Series Inverters User Manual 137
9.6 Reactor Selection
The reactor selections are shown as Table 9-5 and Table 9-6.
Table 9-5 AC reactor selection
Model
AC input reactor AC output reactor
Model
Parameter
(mH-A)
Model
Parameter
(mH-A)
HD30-4T037G/045P HD-AIL-4T037 0.19-75 HD-AOL-4T037 0.08-80
HD30-4T045G/055P HD-AIL-4T045 0.16-90 HD-AOL-4T045 0.06-100
HD30-4T055G/075P HD-AIL-4T055 0.13-115 HD-AOL-4T055 0.04-125
HD30-4T075G/090P HD-AIL-4T075 0.093-150 HD-AOL-4T075 0.035-160
HD30-4T090G/110P HD-AIL-4T090 0.08-180 HD-AOL-4T090 0.03-200
HD30-4T110G/132P HD-AIL-4T110 0.067-210 HD-AOL-4T110 0.02-225
HD30-4T132G/160P HD-AIL-4T132 0.055-255 HD-AOL-4T132 0.016-280
HD30-4T160G/200P HD-AIL-4T160 0.046-305 HD-AOL-4T160 0.013-320
HD30-4T200G/220P HD-AIL-4T200 0.037-380 HD-AOL-4T200 0.011-400
HD30-4T220G/250P HD-AIL-4T220 0.034-415 HD-AOL-4T220 0.01-450
HD30-4T250G/280P HD-AIL-4T25
0.026-530
HD-AOL-4T250
0.009-560
HD30-4T280G/315P HD-AIL-4T280 HD-AOL-4T280
HD30-4T315G/355P HD-AIL-4T315 0.023-600 HD-AOL-4T315 0.007-630
HD30-4T355G/400P HD-AIL-4T355
0.019-760
HD-AOL-4T355
0.006-800
HD30-4T400G/450P HD-AIL-4T400 HD-AOL-4T400
Table 9-6 DC reactor selection
Model
DC reactor
Model Parameter (mH-A)
HD30-4T037G/045P HD-DCL-4T037 0.35-100
HD30-4T045G/055P HD-DCL-4T045 0.29-120
HD30-4T055G/075P HD-DCL-4T055 0.23-150
HD30-4T075G/090P HD-DCL-4T075 0.17-200
HD30-4T090G/110P HD-DCL-4T090 0.14-240
HD30-4T110G/132P HD-DCL-4T110 0.12-290
HD30-4T132G/160P HD-DCL-4T132 0.11-330
HD30-4T160G/200P HD-DCL-4T160 0.09-400
HD30-4T200G/220P HD-DCL-4T200 0.07-500
HD30-4T220G/250P HD-DCL-4T220 0.06-550
HD30-4T250G/280P HD-DCL-4T250
0.05-700
HD30-4T280G/315P HD-DCL-4T280
HD30-4T315G/355P Built-in
HD30-4T355G/400P Built-in
HD30-4T400G/450P Built-in
