Chapter 9 Options Shenzhen Hpmont Technology Co., Ltd
―136― HD30 Series Inverters User Manual
Model
Adaptive
motor
Braking unit
model
Braking resistor
resistance
Braking resistor
power
HD30-4T0P7G 0.75 kW Built-in 250－350 Ω 100 W
HD30-4T1P5G 1.5 kW Built-in 200－300 Ω 200 W
HD30-4T2P2G 2.2 kW Built-in 150－250 Ω 250 W
HD30-4T3P7G/5P5P 3.7/5.5 kW Built-in 100－150 Ω 300 W
HD30-4T5P5G/7P5P 5.5/7.5 kW Built-in 80－100 Ω 500 W
HD30-4T7P5G/011P 7.5/11 kW Built-in 60－80 Ω 700 W
HD30-4T011G/015P 11/15 kW Built-in 40－50 Ω 1 kW
HD30-4T015G/018P 15/18.5 kW Built-in 30－40 Ω 1.5 kW
HD30-4T018G/022P 18.5/22 kW Built-in 25－30 Ω 2 kW
HD30-4T022G/030P 22/30 kW Optional 20－25 Ω 2.5 kW
HD30-4T030G/037P 30/37 kW Optional 15－20 Ω 3 kW
HD30-4T037G/045P 37/45 kW Optional 15－20 Ω 3.5 kW
HD30-4T045G/055P 45/55 kW Optional 10－15 Ω 4.5 kW
HD30-4T055G/075P 55/75 kW Optional 10－15 Ω 5.5 kW
HD30-4T075G/090P 75/90 kW HDBU-4T150 8－10 Ω 7.5 kW
HD30-4T090G/110P 90/110 kW HDBU-4T150 8－10 Ω 9 kW
HD30-4T110G/132P 110/132 kW HDBU-4T150 6－8 Ω 11 kW
HD30-4T132G/160P 132/160 kW HDBU-4T250 6－8 Ω 13.2 kW
HD30-4T160G/200P 160/200 kW HDBU-4T250 4－6 Ω 16 kW
HD30-4T200G/220P 200/220 kW HDBU-4T250 4－6 Ω 20 kW
HD30-4T220G/250P 220/250 kW HDBU-4T250 *2 6－8 Ω *2 11 kW *2
HD30-4T250G/280P 250/280 kW HDBU-4T250 *2 6－8 Ω *2 12.5 kW *2
HD30-4T280G/315P 280/315 kW HDBU-4T250 *2 4－6 Ω *2 14 kW *2
HD30-4T315G/355P 315/355 kW HDBU-4T250 *2 4－6 Ω *2 16 kW *2
HD30-4T355G/400P 355/400 kW HDBU-4T250 *3 4－6 Ω *3 11 kW *3
HD30-4T400G/450P 400/450 kW HDBU-4T250 *3 4－6 Ω *3 14 kW *3
Remark: *2 or *3 is meaning 2 or 3 parallel way.
