Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD30 Series Inverters User Manual ―107―
6.2.19 Group F18 Display Control Parameters
Note: Refer to the《User Manual of HD31 Series Special Inverter for Water and Wastewater application》 for
the water and wastewater display parameters.
No. Name Description Range
factory setting
F18.00 Language selection 0,1
0
It defines the displaying language on the LCD display panel.
• Only when using LCD display panel will F18.00 be enabled.
0: Chinese.
1: English.
F18.01 Displaying contrast of the LCD display panel 1
10
5
To select LCD displaying contrast.
• Only when using LCD display panel will F18.01 be enabled.
F18.02 Set the display parameter 1 during operation 0
49
8
Set the display parameter 2 during operation
F18.04 Set the display parameter 3 during operation 0
49
9
Set the display parameter 4 during operation
F18.06 Set the display parameter 5 during operation 0
49
14
Set the display parameter 6 during operation
F18.08 Set the display parameter 1 at stop 0
49
7
Set the display parameter 2 at stop
F18.10 Set the display parameter 3 at stop 0
49
20
Set the display parameter 4 at stop
F18.12 Set the display parameter 5 at stop 0
49
43
Set the display parameter 6 at stop
The display panel displays parameters which difine the operation status (F18.02－F18.07) and stop
status (F18.08－F18.13).
• It can be cycling displayed by key on the display panel.
• Each display parameter of content can be set as the corresponding 49 statuses.
• For instance: when set F18.08 as 7, it displays stop parameters which is setting frequency at initial
power on.
0: Reserved.
1: Inverter’s rated current.
2: Inverter’s extension function.
• 0: No extension function.
• 1: Water and wastwater applications.
3: The inverter status.
• Refer to parameter d00.10.
4: Master setting frequency source.
5: Master setting frequency.
6: Auxiliary setting frequency.
7: Setting frequency.
8: Reference frequency (after acceleration/ deceleration).
9: Output frequency.
• At running state, indicator is flashing.
10: Setting RPM.
11: Running RPM.
• At running state, indicator is flashing.
6
