Page #37 background imageLoading...
Page #37 background image
Chapter 4 Electrical Installation Shenzhen Hpmont Technology Co., Ltd
20 HD30 Series Inverters User Manual
Model
Input Protection Main Circuit (mm
2
)
Control
Circuit (mm
2
)
MCCB (A) Contactor (A) Supply Cables Motor Cables
HD30-2T015G 125 100 25 25 0.5
HD30-2T018G 160 100 25 25 0.5
HD30-2T022G 200 125 35 35 0.5
HD30-2T030G 200 125 50 50 0.5
HD30-2T037G 250 160 70 70 0.5
HD30-2T045G 250 160 95 95 0.5
HD30-2T055G 350 350 120 120 0.5
HD30-2T075G 400 400 150 150 0.5
HD30-4T0P7G 10 10 1.0 1.0 0.5
HD30-4T1P5G 16 10 1.0 1.0 0.5
HD30-4T2P2G 16 10 1.5 1.5 0.5
HD30-4T3P7G/5P5P 25 16 2.5 2.5 0.5
HD30-4T5P5G/7P5P 32 25 4.0 4.0 0.5
HD30-4T7P5G/011P 40 32 4.0 4.0 0.5
HD30-4T011G/015P 63 40 6.0 6.0 0.5
HD30-4T015G/018P 63 40 6.0 6.0 0.5
HD30-4T018G/022P 100 63 10 10 0.5
HD30-4T022G/030P 100 63 16 16 0.5
HD30-4T030G/037P 125 100 25 25 0.5
HD30-4T037G/045P 160 100 25 25 0.5
HD30-4T045G/055P 200 125 35 35 0.5
HD30-4T055G/075P 200 125 50 50 0.5
HD30-4T075G/090P 250 160 70 70 0.5
HD30-4T090G/110P 250 160 95 95 0.5
HD30-4T110G/132P 350 350 120 120 0.5
HD30-4T132G/160P 400 400 150 150 0.5
HD30-4T160G/200P 500 400 185 185 0.5
HD30-4T200G/220P 600 600 150*2 150*2 0.5
HD30-4T220G/250P 600 600 150*2 150*2 0.5
HD30-4T250G/280P 800 600 185*2 185*2 0.5
HD30-4T280G/315P 800 800 185*2 185*2 0.5
HD30-4T315G/355P 800 800 150*3 150*3 0.5
HD30-4T355G/400P 800 800 150*4 150*4 0.5
HD30-4T400G/450P 1000 1000 150*4 150*4 0.5
Remarks: *2, *3, *4 respectively represent “2, 3 or 4 main circuit cables are in parallel”.
