hpmont MONT20 User Manual

Chapter 5 Function Introduction
MONT20 User Manual V1.6 39
Ref. Code Function Description Setting Range [Default]
F10.09
Internal star-delta relay working mode
0, 1 [1]
0: Operate when it’s faulty.
1: Operate when fault or stop.
F10.10
Current zero offset parameter acquisition method
0 - 2 [0]
0: Get automatically when powering-on.
1: Get by F10.11 - F10.13.
2: Store the zero offset value after power-on to F10.11 - F10.13, and use the value of F10.11 - F10.13 as the
current bias.
• When F10.10 = 2, it will automatically change to 1.
F10.11
U phase zero offset setting
1700 - 2200 [1950]
F10.12
V phase zero offset setting
1700 - 2200 [1950]
F10.13
W phase zero offset setting
1700 - 2200 [1950]
F10.14
Door vane self-learning current judgment
0.01 - 0.50 [0.05A]
F10.15
Speed deviation protection range
5 - 50 [20%]
F10.16
Speed deviation protection detection time
0.0 - 2.0 [0.5s]
F10.17
Overspeed range setting
105 - 120 [110%]
F10.18
Overspeed detection time
0.0 - 2.0 [0.5s]
F10.19
Fermator Syn. motor
0, 1 [0]
0: Normal Syn. door motor.
1: Fermator Syn. door motor.
Note: The control of the Fermator Syn. door motor requires the ordering of non-standard Mont20-FMT (changing
non-standard hardware and software are customized products).
F10.20
Syn. motor Z signal detection
0, 1 [0]
0: Fault detection is allowed.
1: Fault detection shielding.
F10.21
Zt (zhete) Syn. motor
0, 1 [0]
0: Normal Syn. door motor.
1: Zt (zhete) Syn. door motor.
Note: When it set to 1, the Syn. door motor Z signal is a special signal with duty cycle.
