Chapter 5 Function Introduction
MONT20 User Manual V1.6 25
5.2.2 F01: Motor Parameters
Ref. Code Function Description Setting Range [Default]
F01.01 Motor rated voltage 1 - 300 [220V]
F01.03 Motor rated frequency 1.00 - 99.99 [50.00Hz]
In order to ensure the control performance, the motor should match the power level of MONT20.
Generally, F01.05 = 1.00. If the encoder is not installed on the motor axis, user should set F01.05 according to
actual condition.
• F01.05 is valid only for Asyn. motor closed loop vector control (F00.06 = 1).
Motor parameter auto-tuning
0: No action.
1: Motor parameter auto-tuning.
• Set F00.03 = 0, and correctly set motor nameplate parameter (F01.00 - F01.04).
• Set F01.06 = 1, and press (RUN key) to start motor parameter auto-tuning. Press (STOP key) to
stop auto-tuning; When auto-tuning is finished, F01.06 restores to 0 automatically.
• When Syn. motor is auto-tuning, the motor will recognise the pole angle and direction of encoder. When
Asyn. motor is auto-tuning, the belt pulley must be taken off.
• Refer to section 6.1, on page 41 for details about motor parameter auto-tuning.
Only valid for Asyn. motor, i.e, when F00.06 = 0 (Asyn. motor open-loop vector control) or 1 (Asyn. motor
closed loop vector control).
Magnetic pole position angle
Only valid for Syn. motor, i.e, when F00.06 = 2 (Syn. motor closed loop vector control).
0.00 - 99.99Ω [Depend on MONT20]
F01.10 Rotor resistance 0.00 - 99.99Ω [Depend on MONT20]
0 - 9999mH [Depend on MONT20]
F01.12 Rotor inductance 0 - 9999mH [Depend on MONT20]
0 - 9999mH [Depend on MONT20]
F01.14 Slip compensation gain 50.0 - 200.0 [100.0%]
