hpmont MONT20 User Manual

Chapter 5 Function Introduction
38 MONT20 User Manual V1.6
5.2.11 F10: Advanced Parameters
Ref. Code Function Description Setting Range [Default]
F10.00
Electromagnetic valve door vane opening delay time
0 - 9999 [0ms]
F10.01
Electromagnetic valve door vane closing delay time
0 - 9999 [0ms]
F06.01 adds the function of No.6 and No.16, which used to control the door vane solenoid valve to open.
This function is used together with F10.00 (electromagnetic valve door vane opening delay time) and F10.01
(electromagnetic valve door vane closing delay time).
• When the OD command is given, the control relay opens the door vane solenoid valve and maintains zero
speed running within F10.00. After this time delay, it runs according to the normal curve.
• When the CD command is given, when the door is closed to the door closing position and the zero speed
running is maintained, after the F10.01 time, the control relay closes the door vane solenoid valve to close.
F10.02
OD creeping time
0.0 - 5.0 [0.7s]
F10.03
CD creeping time
0.0 - 5.0 [0.7s]
F10.04
Door vane distance
0 - 9999 [0 pulse]
There are two ways to get it:
• 1: The door width automatic learning with hall door (F02.05 is set to 2).
•
2: The door vane distance can also be obtained by the group d through the monitoring pulse d01.00.
F10.05
Automatical generation of switch door curve Dec. point
0, 1 [0]
0: By parameter setting.
1: Automatic calculation by software.
F10.06
Open the door to maintain torque automatically calculated
0, 1 [0]
0: By parameter setting.
1: Automatic calculation by software.
• When F10.06 = 1, the software automatically calculates the switch door Dec. point.
• F10.02 and F10.03 can set the creeping time at the end of the switch door, and F10.04 is the actual door
vane distance.
F10.07
OD blocked
0, 1 [0]
0: Door opening stop.
1: After being blocked, keep the door open, the multi-function output can output the blocked signal, and the
elevator control system can freely choose to open or close the door according to the blocked signal.
• When it is set to 1, after the door motor is blocked, the Max. output torque is 1.1 times the resistance
torque of door opening.
F10.08
CD blocked mode
0, 1 [0]
0: Blocked and re-open the door.
1: After being blocked, keep the door close, the multi-function output can output the blocked signal, and the
elevator control system can freely choose to open or close the door according to the blocked signal.
• When it is set to 1, after the door motor is blocked, the Max. output torque is 1.1 times the resistance
torque of door opening.
