hpmont MONT20 User Manual

Chapter 5 Function Introduction
30 MONT20 User Manual V1.6
Ref. Code Function Description Setting Range [Default]
F05.14 Switching torque of low speed OD/CD 30.0 - F07.07 [70.0%]
Define the torque switching value between door width self-learning and torque at initial power on. The
setted value is percentage of motor rated torque.
F05.15 Torque at OD resistance 0.0 - F07.07 [100.0%]
F05.16
Time at OD resistance
0 - 4999 [1600ms]
F05.15 corresponds to motor rated torque. The smaller value is, the smaller resistance.
• When F05.15 = 0, it’s invalid.
• During OD process, door motor outputs fully open signal of door and will not detect OD resistance.
• When OD is resisted, door motor stops responding to OD command. It will respond until time of F05.16 is
finished.
• When OD is resisted, if there is CD command, door motor responds to it and closes the door.
F05.17
Stop time at OD resistance
0 - 9999 [3000ms]
Defines that after the door opening is resisted, the time of F05.17 can re-respond to the door opening signal.
• When F05.17 = 9999ms, the door motor does not respond to the door open command. Only after
responding to the door closing command, it will respond to the door open command again.
5.2.7 F06: Boost Parameters
Ref. Code Function Description Setting Range [Default]
F06.00 DOA, DCA, PA output pole selection 0, 1 [1]
0: The signal connects which represents fully OD/CD and door position output (equal to the relay normally
closed contact).
1: The signal disconnects which represents fully OD/CD and door position output (equal to the relay normally
open contact).
F06.01 PA function selection 0 - 19 [0]
0: Door position output.
1: Re-opening signal outputs at CD resistance.
• Set F06.01 = 1, the re-opening signal is valid.
When the CD resistance signal is valid, the re-
opening signal starts to output. When fully re-
open, the re-opening signal will stop output.
2: Complete OD.
3: Complete CD.
4: Fault output.
5: Running (normally open).
6: Door vane solenoid valve output (normally open).
7 - 9: Unused.
10: Door position output (normally closed).
11: Closed door resistance re-opening door signal
output (normally closed).
12: Complete OD (normally closed).
13: Complete CD (normally closed).
14: Fault output (normally closed).
15: Running (normally closed).
