hpmont MONT20 User Manual

Chapter 5 Function Introduction
MONT20 User Manual V1.6 31
Ref. Code Function Description Setting Range [Default]
16: Door vane solenoid valve output (normally
closed).
• Door vane solenoid function (No.6 or No.16) is
used to control the door vane solenoid valve to
open.
• Fit with F10.00 (electromagnetic valve vane
opening delay time) F10.01 (electromagnetic
valve vane closing delay time).
• When the door open command is given, the
control relay opens the door vane solenoid valve
and maintains zero speed operation within
F10.00. After this time delay, it runs according to
the normal curve.
• When the door closing command is given, the
door is closed to the door closing position and
the zero speed operation is maintained, after
F10.01, the control relay closes the door vane
solenoid valve to close.
17 - 19: Unused.
F06.02
Input terminal filter time
2 - 300 [10ms]
Set the sensitivity of DI input terminal. If the DI terminal is interfered and leads to unexpected action, increase
value of F06.02 to improve the immunity from interferance, but that will reduce the sensitivity of DI.
F06.03
DI1 funtion selection
0 - 22 [11]
F06.04 DI2 funtion selection 0 - 22 [12]
F06.05
DI3 funtion selection
0 - 22 [13]
F06.06 DI4 funtion selection 0 - 22 [14]
F06.07
DI5 funtion selection
0 - 22 [0]
0: No funtion.
1: OD speed switching NO (normally open) input.
2: OD limit NO input.
3: CD speed switching NO input.
4: CD limit NO input.
5: Light curttain, contact board NO input.
6: Low speed signal (SS).
7: OD command (OD).
8: CD command (CD).
9: Fault reset (RST).
10: Motor overheating normally open input.
11: OD speed switching NC (normally closed) input.
12: OD limit NC input.
13: CD speed switching NC input.
14: CD limit NC input.
15: Light curtain, touch board NC input.
20: Motor overheating NC input.
21: The door lock signal is normally open.
22: The door lock signal is normally closed.
• When the No. 21, 22 function is selected, the
door motor in-position signal output must be
output after the door lock signal is closed.
F06.08
DC resistance Aux. detection time
0 - 4999 [0ms]
If pulse does not change within the time of F06.08, DC is resisted.
• Below conditions should be met:
• 1. F00.02 = 1 (distance control);
• 2. F00.06 = 0 (Asyn. motor open-loop vector control) or F00.06 = 3 (Asyn. motor flux vector control).
• F06.08 < 1000ms, do not detect DC resistance.
• There is no relationship between DC resistance detection and DC torque resistance (F05).
