Chapter 5 Function Introduction
32 MONT20 User Manual V1.6
Ref. Code Function Description Setting Range [Default]
F06.09 Percentage of door position output 0.1 - 99.9 [90.0%]
When door position > F06.09, the door position output signal (PA) is valid.
• Only valid when F06.01 = 0 (door position output).
F06.10 Resistance Dec. time 0.1 - 2.0 [0.5s]
Define the time when CD resistance occurs, the current CD speed will decelerate to zero speed.
• If F06.10 is too small, the door will shake violently at Dec. process. If F06.10 is too big, the Dec. of door will
be too slow.
F06.11 Action selection of door motor when revoke run command 0 - 2 [2]
0: The torque is maintained during complete OD/CD, and runs at zero speed in other positions.
1: Stop running.
2: Only maintain the torque during complete OD/CD.
F06.12 Auxiliary parameter 1 00000 - 11111 [00000]
Ten thousand: Detect CD resistance 1/3 distance from CD acts
• 0: Detect CD resistance.
• 1: Not detect CD resistance.
Thousand: Function of stop key in terminal control
• 0: Invalid.
• 1: Valid. During running, continuously press (STOP key), the system
stops, and ”STOP” will display on LCD. Press (STOP key) again, the
system returns to normal.
Hundred: CD limit switching mode
• 0: Do not learn the CD limit position during door
width self-learning.
• 1: Learn the CD limit potision during door width
self-learning. When this signal is valid, the system
can reset to current position automatically.
Ten: Demo mode enable
• 0: Enable manually.
• 1: Enable automatically.
Unit: OD/CD priority selection
• 0: OD priority.
• 1: CD priority.
