Chapter 2 Product Information
MONT20 User Manual V1.6 3
Chapter 2 Product Information
2.1 Rated Value
Power (kW) Capacity (kVA) Rated Input Current (A) Rated Output Current (A) G.W. (kg)
0.4 1.0 5.8 2.5 1.7
2.2 Technical Data
Electrical Specification
Input voltage
Single phase: 200 - 240V
Fluctuating within ±5%, imbalance rate <3%
Input frequency 50/60Hz ± 5%
Output voltage 0V - input voltage
Output frequency 0.00 - 99.99Hz
Control Characteristic
Control mode SVC; VC
Speed range 1:100 (SVC); 1:1000 (VC)
Speed accuracy ±0.5% (SVC); ±0.05% (VC)
Starting torque 180% rated torque at 0.5Hz (SVC); 180% rated torque at 0Hz (VC)
Frequency setting Keypad setting
Resolution Frequency: 0.01Hz; Current: 0.01A
Capacity 150% rated output current for 1 minute, 180% rated output current for 1 second
Function
Main function
• When controlling AC Asyn. motor, it supports dynamic tuning of motor parameter
• When controlling AC PMSM, it supports no-load/load tuning and encoder zero
position of motor parameter
• Support normal ABZ encoder, achieve closed loop vector control of AC PMSM
• Support receiving open collector or push-pull encoder input signal
• Distance control and speed control
• Support door width self-learning, auto demo loop, resistance auto recognization and
parameter upload/download (optional keypad)
Protection
Overload protection, overvoltage protection, under-voltage protection, overcurrent
protection, inter-phase short-circuit protection, etc.
