hpmont MONT20 User Manual

Appendix A Parameter
MONT20 User Manual V1.6 59
Appendix A Parameter
Property Modification:
“*”: It denotes that the value of this parameter is the actual value which cannot be modified.
“×”: It denotes that the setting of this parameter cannot be modified when MONT20 is in run status.
“○”: It denotes that the setting of this parameter can be modified when MONT20 is in run status.
Ref. Code Function Setting Range Default
Attribute
Setting
d00: System Parameters, on page 21
d00.00 Controller series MONT20 0x0020 *
d00.01 Controller rated power 200 - 400W 400W *
d00.02 Controller rated current 0.01 - 9.99A 2.50A *
d00.03 Controller software version 1.00 - 9.99 Actual *
d00.04
Controller non-standard
software version
1.00 - 9.99 Actual *
d00.05
External keypad software
version
1.00 - 9.99 Actual *
d01: Drive Status Parameters, on page 21
d01.00 Door position pulse 0 - Max. door width Actual *
d01.01 Door position percentage 0.0 - 100.0% Actual *
d01.02 Complete OD/CD signal
From right to left: Complete OD pulse,
complete CD pulse, complete OD torque,
complete CD torque
• 0: Not complete
• 1: Complete
Actual *
d01.03 Set frequency 0.00 - 99.99Hz Actual *
d01.04 Output frequency 0.00 - 99.99Hz Actual *
d01.05 Output voltage 0 - 999V Actual *
d01.06 Output current 0.00 - 9.99A Actual *
d01.07 Output torque 0.0 - 200.0% Actual *
d01.08 Bus voltage 0 - 999V Actual *
d01.09 Input terminal status 1
Unit - ten thousand correspond to DI1 - DI5
0: Terminal disconnects with common
terminal
1: Terminal connects with common terminal
Actual *
