Chapter 5 Function Introduction
MONT20 User Manual V1.6 33
Ref. Code Function Description Setting Range [Default]
F06.13 Auxiliary parameter 2 00000 - 11111 [00001]
Ten thousand: Abnormal shutdown protection is opened
• 0: Open.
• In the process of closing the motor, if the complete CD signal has not been output before, then when the
total number of blocked CD is more than 20 times and the complete CD signal is not detected, it will
alarms E0012 (abnormal closing fault).
• The motor stops for 20 minutes after the fault and the fault is automatically reset.
• 1: Not open.
Thousand: Current slope rise
• 0: Start current direct setting.
• 1: Start current slope rise.
Hundred: Speed loop amplification
• 0: KP is original value.
1: KP amplify by 4 times.
Ten: Over-current auto reset enable
• 0: Not enable.
1: Enable.
Unit: Over-vlotage auto reset enable
• 0: Not enable.
• 1: Enable.
F06.14 On board LCD brightness adjustment 0 - 100 [70%]
0%: Darkest.
100%: Brightest.
F06.15 Carrier frequency 4 - 16 [8k]
Running speed when prising door for Asyn. motor open-loop
F06.17 CD time protection 0 - 30 [0s]
When setting time ≤ 2s, do not protect CD.
When setting time > 2s, time counts from the minute giving CD command. If complete CD signal is not
received during this process, it will re-open the door.
F06.18 Flux vector voltage compensation 0 - 40 [10%]
Flux vector complete CD holding frequency
F06.20 Flux vector complete OD holding frequency 0.01 - 5.00 [1.00Hz]
Delay switching time of flux vector speed switching to torque
F06.22 Frequency range of flux vector no detection OD/CD resistance 0.10 - 15.00 [7.00Hz]
Flux vector OD voltage compensation
When closing, flux vector voltage compensation = F06.18.
When opening, flux vector voltage compensation = F06.18 + F06.23.
Cut-off point of flux vector voltage compensation frequency
