Figure 10-2 Installing the PGND cable
Step 3 Install the equi-potential cable.
Determine the installation position of the equi-potential cable in each cabinet, as shown in Figure
10-3 and Figure 10-4. For details, see Step 2.
Figure 10-3 Installing the equi-potential cable (scenario 1)
