4.2.2.12 (Optional) Replacing a Wet Film Humidier
Prerequisites
The humidier needs to be replaced.
A spare humidier of the same model is available and functional.
Tools:
at-head screwdriver and water bucket
Context
The humidier can be maintained only from the rear.
Procedure
Step 1 Tap Shutdown on the LCD home screen and turn
o the smart cooling product
switch and QF4 in the PDC.
NO TICE
Exercise caution because the device is still energized after it is shut down on the
LCD.
Step 2 Open the rear door and remove the air lter.
Step 3 Remove the hose clamp from the water inlet pipe of the wet lm humidier, and
remove the water inlet pipe.
Figure 4-40 Removing the water inlet pipe
Step 4 Remove the screws that secure the humidier sheet metal to the driver, remove
the sheet metal, move the wet lm leftward, and pull out the humidier.
FusionDC1000A Prefabricated All-in-One Data
Center
Maintenance Guide (IT Scenario) 4 Parts Replacement
Issue 01 (2021-04-20) Copyright © Huawei Technologies Co., Ltd. 95
