FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
Copyright © Huawei Technologies Co., Ltd.
A step ladder is required in this step.
If no fan assembly is configured, remove the upper sealing plate from the aisle
containment in the same manner.
Figure 3-13 Removing a fan
Step 6 Remove the sealing plate from the bottom of the aisle containment using a Phillips
screwdriver, as shown in Figure 3-14.
