FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
Copyright © Huawei Technologies Co., Ltd.
(Optional) Deploying MPUs in Cluster Mode. For details, log in to the
https://e.huawei.com/, search for the VCN product documentation, open the
documentation, and see the section (Optional) Deploying MPUs in Cluster Mode.
For the VCN500, search for VCN500 Product Documentation. For the VCN540, search for
VCN510&VCN520&VCN540 Product Documentation.
6.3.10.4 Setting Parameters on the VCN IVS Client
Prerequisites
The network communication between the VCN and the camera is normal.
Procedure
Step 1 Install the VCN IVS client.
1. Download the VCN IVS client.
You can obtain the VCN IVS in either of the following ways:
Obtain the HW_IVS_Client.exe file from the software CD-ROM delivered
with the VCN.
1. Log in to the VCN OMU Portal, choose Local Configuration > Basic
Configuration, and view Current version.
2. Log in to https://support.huawei.com/enterprise/, and search for Client
Package.zip followed by the VCN model (Client Package.zip VCN540
for example). In the search result, click the Software Download tab, click
the version and patch number corresponding to the current version, and
download the Client Package.zip software package.
Figure 6-21 Client Package search result
2. Double-click HW_IVS_Client.exe, adopt the default installation mode, and wait until
the installation is complete.
3. Double-click the client program and on the login page, enter the user name Admin and
preset password Change_Me, and set Server address to the actual service IP address
(VCN IP address) and Port to 9900.
If the VCN IVS and VCN are deployed in the same LAN, set Server IP address to the VCN internal IP
address (192.168.248.55, for example). If the VCN IVS is on an extranet and the VCN is on a LAN, set
Server IP address to the VCN external IP address.
4. Click Log In to access the client home page.
