Huawei iManager NetEco 6000 User Manual

iManager NetEco 6000
Device Installation and Commissioning Guide
6 Adding Devices
Issue 03 (2019-03-10)
Copyright © Huawei Technologies Co., Ltd.
129
Name
Description
Name
Name of the device.
Direction
Set to Horizontal by default.
Chooses in the dropdown box Horizontal or Vertical.
Layout
Set to single-row wide aisle1 by default.
Chooses behind in the dropdown box the single-row wide aisle1, single-row
wide aisle2, dual-row wide aisle, single-row narrow aisle1, single-row
narrow aisle2 and single-row dual aisle.
Half-Size
Cabinet
Set to 11 by default.
The value is an integer ranging from 4 to 50.
Aisle
Size
Set to 1200 by default.
The value is an integer ranging from 0 to 65535.
Aisle
Containm
ent Type
Set to Cool Aisle by default
Chooses in the dropdown box Hot Aisle or Cool Aisle.
Optional list
Parent
Object
Management domain of the device.
The NetEco automatically identifies this name.
Type
Device type.
The NetEco automatically identifies this name.
Manufact
urer
Manufacturer of the device.
The value contains 1 to 64 characters.
Serial
Number
Device number.
The value contains 0 to 64 characters.
Location
Location of the device.
The value contains 0 to 64 characters.
Install
Mode
Set to Floor Build In by default.
Installation mode of the device, including Floor Build In, Cabinet Build In,
Wall Build In and Ceiling Installation.
Wire
Type
Set to Ascending Line by default.
Wiring mode of the device, including Ascending Line, Down Line and Floor
Line.
Airflow
Type
Set to Vertical Under-Floor Air-Distribution by default.
A total of five airflow types, such as the Vertical Under-Floor
Air-Distribution, Horizontal Displacement Air-Distribution and Side
Displacement Air-Distribution.
Height
Set to 2000 by default.
Chooses the 2000 number or the 2200 number in the dropdown box.
