iManager NetEco 6000
Device Installation and Commissioning Guide
Copyright © Huawei Technologies Co., Ltd.
Table 6-7 MODBUS-TCP device parameter description
Set this parameter to the device IP address.
Set this parameter to the port through which the device connects to
the collector.
NOTE
The port number is 502 by default. You can modify the port number based on
requirements.
Fixed value: 2.
NOTE
This parameter does not need to be configured.
Timeout duration for connection test (set to 3s by default)
Indicates the connection mode of a device. You can set this
parameter to Non-SSL Connection or SSL Connection.
If you modify Connection Mode on the NetEco, you must modify
Connection Mode on the WebUI of the device at the same time.
NOTE
Connection Mode for the NetEco and device must be the same.
By default, Connection Mode is set to SSL Connection for the NetEco
and device.
NOTE
Battery detectors accessed through the UPS do not support device software
management.
Indicates the re-authentication password for the NetEco and device.
1. Click Modify.
2. In the displayed dialog box, enter the New Password and
Confirm Password.
NOTE
The default re-authentication password for the NetEco and device is
Modifyme_123.
The device password should be consistent with the NetEco password.
If the password does not meet requirements, modify it on the device.
3. Select Send To Device.
NOTE
If you click YES, the re-authentication password for the NetEco and device
is changed at the same time. If you click NO, only the re-authentication
password of NetEco is changed on the server.
4. Click OK.
Step 7 Click Connection Test to start the connection test.
Step 8 After the connection test is successful, click in the toolbar to save the device
information.
