iManager NetEco 6000
Device Installation and Commissioning Guide
Copyright © Huawei Technologies Co., Ltd.
Procedure
Step 1 Set the IP address for the UPS5000 on the LCD.
1. Choose Settings > Communication.
The preset password is 000001.
2. Set IP address allocation to Manual, and set IP address, Subnet mask, and Gateway.
Step 2 Add a user and set user rights on the UPS5000 WebUI.
1. On the PC with an IP address in the same network segment as the UPS5000, type the
UPS5000 IP address in the address box of a browser and press Enter. The UPS5000 IP
address is set in step 1.
2. Enter the User name and Password of the UPS5000 and click Login.
The preset user name and password are admin and Changeme respectively for the UPS5000.
3. Choose Config. > Site Config..
4. In the SNMP area, set SNMP version to SNMPv3, and set SNMP port to 161.
Figure 6-34 Setting SNMP parameters
5. Click Add in SNMP.
Figure 6-35 Setting SNMP parameters_02
6. Set User name, MD5 Password, and DES Password for the user to be added.
Record the values of User name, MD5 Password, and DES Password because they are
required when you create a UPS5000 on the NetEco.
You are advised to set MD5 Password and DES Password to different values.
7. Click Add in SNMP Trap.
To Next Page
