Function of the RS485 port on the ECC500 V6: When you create an RS485 device on the
NetEco, you need to enter the port number for connecting to the device on the NetEco.
Only the device connected to the RS485 communciation card requires a port number. The devices
connected to the AI/DI card and independent deployment AI/DI unit do not require a port number.
The RS485 communications card can be inserted into any one or more slots among slots 1-4
on the ECC500 V6 collector. The RS485 port numbers vary based on slots. Figure 6-51 shows
the ECC500 V6 collector slots. Table 6-22 shows the mappings between slots and port
numbers.
During onsite operations, connect the slots on the collector based on site requirements. The
following figure is only for reference.
Figure 6-51 ECC500 V6 collector slots
Table 6-22 Mappings between port numbers and slot numbers
----End
