iManager NetEco 6000
Device Installation and Commissioning Guide
Copyright © Huawei Technologies Co., Ltd.
Procedure
Step 1 Choose Configuration > Configuration Management > Access Control Management
from the main menu. The Access Control Management window is displayed.
Step 2 Click Create on the Access Controllers List tab page.
The Data Center Planning page is displayed.
Step 3 Add an access controller to the Data Center Planning page.
1. Select the management domain to add a device.
2. In the lower-left corner of the page, click the Device tab.
3. Click the drop-down list box in Type and select Access Controller
4. Select an access controller and drag its icon to the management domain.
To delete a device, click the device and choose Delete under .
5. The A8802RS access controller shown in Figure 6-76 is used as an example.
Figure 6-76 Setting access controller parameters
