NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm)
Copyright © Huawei Technologies Co., Ltd.
Figure 3-51 Position and cable routing out of the unit
A humidity and temperature sensor should be installed 1.5 m above the floor.
Each smart cooling product supports three cold aisle humidity and temperature sensors and three hot
aisle humidity and temperature sensors at most.
Setting the DIP Switch on the Humidity and Temperature Sensor
Figure 3-52 shows the DIP switch on a humidity and temperature sensor.
Figure 3-52 DIP switch
You need to set the DIP switch to change the communications address of sensors. Table 3-17
describes the operation description.
