Data Plan When Remote Software Commissioning Using GE Upstream
Transmission Is Enabled
Configuration
Item
Data Remarks
Ethernet cascading
port on the OLT
ETHB cascading board: 0/3/0
OPGD cascading board: 0/2/0
None
Management VLAN
and IP address of the
OLT
ID of the management VLAN: 8
Type of the management VLAN:
smart
Management IP address:
192.168.50.1/24
Here we take the scenario of "to
remotely log in to the ONU from
the OLT for configuration" for
example, so we need to ensure
that the management VLAN of
the OLT is the same as that of the
ONU and that the management IP
address of the OLT is in the same
network segment as that of the
ONU.
Management VLAN
and IP address of the
ONU
ID of the management VLAN: 8
Type of the management VLAN:
smart
Management IP address:
192.168.50.2/24
Management profile
of the ONU
ID: 64
Name: snmp-profile_64
SNMP version: SNMPv2c
None
Data Plan When Remote Software Commissioning Using GE Upstream
Transmission Is Disabled
Configuration
Item
Data Remarks
Ethernet cascading
port on the OLT
ETHB cascading board: 0/3/0
OPGD cascading board: 0/2/0
None
Management VLAN
and IP address of the
OLT
ID of the management VLAN: 8
Type of the management VLAN:
smart
Management IP address:
192.168.50.1/24
Here we take the scenario of "to
remotely log in to the ONU from
the OLT for configuration" for
example, so we need to ensure
that the management VLAN of
the OLT is the same as that of the
ONU and that the management IP
address of the OLT is in the same
network segment as that of the
ONU.
Management VLAN
and IP address of the
ONU
ID of the management VLAN: 8
Type of the management VLAN:
smart
Management IP address:
192.168.50.2/24
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1028
