– Auth User Name: 80001234@softx3000.huawei.com
– Password: iadtest1
– Associated POTS: 1 (binding port TEL1 on the ONU)
– Select Enable to enable the voice user configuration.
c. Click Apply to apply the configuration.
d. Register User Name: 80001235
e. Auth User Name: 80001235@softx3000.huawei.com
f. Password: iadtest2
g. Associated POTS: 2 (binding port TEL2 on the ONU)
h. Select Enable User to enable the voice user configuration.
i. Click Apply to apply the configuration.
NOTE
l The parameters of the SIP-based voice user must be consistent with the corresponding
configuration on the softswitch.
l If Associated POTS is 1, port TEL1 on the ONU is bound. If Associated POTS is 2, port TEL2
on the ONU is bound.
5. (Optional) Configure a route.
Perform this operation if the IP address of the ONU and the IP address of the voice
server are in different network segments.
a. Choose Route > Default Route Configuration from the main menu.
b. Select Enable the default route and set WAN name to
1_VOIP_R_VID_300.
Figure 12-8 shows the settings.
Figure 12-8 Configuring a route
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1167
