Page #136 background imageLoading...
Page #136 background image
system reports alarms if the working environment of the power system does not meet
requirements.
Step 9 Configure required parameters for the rectifier module.
Run the power module-num command to configure the required parameters for the rectifier
module.
Step 10 Configure the external extended digital variables of the power system.
Run the power outside-digital command to configure the external extended digital variables of
the power system.
Step 11 Query the information about the configuration parameters and environment parameters of the
power system.
Run the display power system parameter and display power environment parameter
commands to query the configuration parameters and environment parameters of the power
system.
Step 12 Run the display power alarm command to query the alarm information, and ensure that no
alarm is generated for the monitored objects except the door status.
Step 13 Save the data.
Run the quit command to exit the SMU mode, and run the save command to save the data.
----End
Result
After the configuration, the ETP4830 power system works properly and monitors the configured
parameters. If the status of a monitored parameter becomes abnormal, an alarm is generated on
the device.
Data Plan
Table 1-35 provides the data plan for configuring the monitoring parameters of the ETP4830.
Table 1-35 Data plan for configuring the power monitoring using the ETP4830
Item Data Plan for the F01S300 Cabinet
EMU Type: SMU
SN: 1
Subnode ID: 0
NOTE
The subnode ID must be the same as the subnode setting of the corresponding
DIP switches on the EMU, but the subnode ID must be different from IDs of
the other subnodes on the same bus.
Charging
parameters of the
battery
Charging mode of the battery: automatic
Equalized charging voltage of the battery (V): 56.5
Float charging voltage of the battery (V): 53.5
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
111
