1. Configure the gateway of the route from the U2000 server to network segment
10.50.1.0/24 to 10.10.1.1.
– In the Solaris OS, do as follows:
Run the route add 10.50.1.0 10.10.1.1 command to add a route.
Run the netstat -r command to query the information about the current routing
table.
– In the Windows OS, do as follows:
Run the route add 10.50.1.0 mask 255.255.255.0 10.10.1.1 command to add a
route.
Run the route print command to query the information about the current routing
table.
NOTE
When the IP address of the network management port and the IP address of the U2000 are in
the same network segment, you need not configure the routing information.
2. Set the SNMP parameters.
a. Choose Administration > NE Communicate Parameter > Default Access
Protocol Parameters from the main menu.
b. Choose SNMP v3 Parameter on the Default Access Protocol Parameters tab
page. Then click Add and set the SNMP parameters, as shown in Figure 1-57.
Figure 1-57 Set the SNMP parameters
After selecting corresponding protocols in Priv Protocol and Auth Protocol,
click
next to the parameter, and set the passwords of data encryption protocol
and authentication protocol, as shown in Figure 1-58.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
146
