l Queue priority of GEM ports 0 and 1: 3, 1
NOTE
When the QoS mode is PQ, the default queue priority is 0.
huawei(config-gpon-lineprofile-10)#gem add 0 eth tcont 5 priority-queue 3
huawei(config-gpon-lineprofile-10)#gem add 1 eth tcont 5 priority-queue 1
l Mode of the mapping from the GEM port to D-CMTS services: VLAN (default)
l Index of the GEM port to which the management service flows in VLAN 8 are mapped: 0
l Index of the GEM port to which the service flows in VLAN 100 are mapped: 1
l Index of the GEM port to which the service flows in COPS connection VLAN 1000 are
mapped: 2
huawei(config-gpon-lineprofile-10)#mapping-mode vlan
huawei(config-gpon-lineprofile-10)#gem mapping 0 0 vlan 8
huawei(config-gpon-lineprofile-10)#gem mapping 1 1 vlan 100
huawei(config-gpon-lineprofile-10)#gem mapping 1 2 vlan 1000
Run the commit command to make the configured parameters take effect.
huawei(config-gpon-lineprofile-10)#commit
huawei(config-gpon-lineprofile-10)#quit
(Optional) Configure an alarm profile.
l The ID of the default GPON alarm profile is 1. In this profile, the thresholds for all alarm
parameters in the default alarm profile are 0, which indicates that no alarm is generated.
l This section uses the default alarm profile and therefore the alarm profile does not need to
be configured.
l To add an alarm profile for monitoring the performance of activated D-CMTS lines, run the
gpon alarm-profile add command.
Step 2 Add a D-CMTS to an OLT.
The D-CMTS connects to a GPON port on the OLT through an optical fiber. You can configure
the D-CMTS only after adding it to the OLT.
1. Add a D-CMTS.
The following configurations are used as an example to add a D-CMTS: The management
mode is SNMP; the ID of the line profile bound to the D-CMTS is 10.
To add a D-CTMS in offline mode, do as follows:
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#ont add 1 1 sn-auth 48575443E6D8B541 snmp ont-
lineprofile-id
10 desc MA5633_0/3/1/1_lineprofile10
To automatically find a D-CMTS, do as follows:
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#port 1 ont-auto-find enable
huawei(config-if-gpon-0/3)#display ont autofind 1
//This command displays the information about all automatically discovered
D-CMTSs that are connected to the GPON port through an optical splitter.
------------------------------------------------------------
Number : 1
F/S/P : 0/3/1
Ont SN : 48575443E6D8B541
Password : 0x30303030303030303030(0000000000)
Loid : 000000000000000000000000
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1748
