Device Item Data
Associated protection
switching
A protection group is associated with the status of
upstream Ethernet ports.
NOTE
l To detect the link status at the IP layer (the
connection status of the OLT upstream network),
you need to associate the protection group with
BFD sessions.
l To detect a Layer 2 physical link fault, you need to
associate the protection group with the status of the
upstream Ethernet port.
In this example, the protection group is associated with
the status of the upstream Ethernet port.
OLT_B The data plan is the same as that of OLT_A.
Table 17-8 Data plan for configuring automatic transmission of power distribution site
information in the electrical power system over Ethernet-ONU side
Device Configurati
on Item
Data Remarks
ONU_A Inband
management
IP address
IP address: 192.168.50.2/24 -
Traffic
profile
l Index 10 (used for transmitting the
power distribution site
information)
l Index 11 (used for transmitting
GOOSE packets)
-
Service port Eth port: 0/1/1 -
Uplink port GPON port: 0/0/0, 0/0/1 -
Uplink
VLAN
l Smart VLAN 100 (used for
transmitting power distribution site
information)
l Smart VLAN 101 (used for
transmitting GOOSE packets)
The uplink VLAN
must be the same
as the CVLAN on
the OLT.
Priority The 802.1p priority is used: The
priority of power distribution site
information is 1 and the priority of
GOOSE packets is 6.
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1834
