Configuration Item Data Remarks
Attributes of the VLAN
Layer 3 interface
l Uplink port: 0/0/0
l VLAN ID: 30
l IP address of the VLAN Layer 3
interface: 10.1.1.3
The IP address of
the master station
server is 10.1.1.2.
Attributes of the serial
port
l Serial port ID: 0/2/0
l Working mode: rs485
l Baud rate: 2400 bit/s
The default baud
rate specified in the
DL645-2007 Multi-
Function Watt-
Hour Meter
Communication
Protocol is 2400 bit/
s.
Ensure that the
serial port attributes
are the same as
those on the
interconnected
terminal unit.
Connections of the serial
port
l Connection ID: 1
l Transmission mode: tcp-server
l Local port ID: 3000
l Serial port frame type: none
If a remote port ID
is not specified on
an ONU, the system
obtains the port ID
based on the
connection packets
received on the
serial port from the
remote port.
NOTE
When specifying a
remote port ID on an
ONU, ensure that it
is the same as the ID
of the source port
sending connection
packets.
Procedure
Step 1 Configure the OLT.
1. Create a service VLAN and add an uplink port to it.
The ID of the service VLAN is 30 and the uplink port added to service VLAN 30 is 0/19/0.
huawei(config)#vlan 30 smart
huawei(config)#port vlan 30 0/19 0
2. (Optional) Configure uplink aggregation.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1851
