Huawei SmartAX MA5600T User Manual

Data Plan
Table 17-9 provides the data plan for the optical line terminal (OLT) and Table 17-10 provides
the data plan for the ONU.
Table 17-9 Data plan for the OLT
Configuration Item Data
Virtual local area network
(VLAN)
l Uplink port: 0/19/0
l Inband management VLAN 8 with VLAN type
smart
l Service VLAN 30 with VLAN type smart
IP address Inband management IP address: 192.168.50.10/24
GPON service board
l Port ID: 0/3/1
l ONT ID: 1
l ONU authentication mode: SN
l ONU serial number (SN): 48575443E6D8B541
Dynamic bandwidth allocation
(DBA) profile
l Profile name: SerialAccess
l Type: type3
l Assured bandwidth: 20 Mbit/s
l Maximum bandwidth: 50 Mbit/s
ONU line profile
l ONU line profile 10 bound to DBA profile
SerialAccess
l GPON encapsulation mode (GEM) port ID: 0
(inband management service port ID)
l GEM port ID: 1 (transparent transmission service
port ID)
l Transmission container (T-CONT) ID: 5
ONU management mode Simple Network Management Protocol (SNMP)
Table 17-10 Data plan for the ONU
Configuration Item Data Remarks
Attributes of the inband
management interface
l Uplink port: 0/0/0
l VLAN ID: 8
l Inband management IP address:
192.168.50.2/24
l Index of a traffic profile: 6 (default
value)
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1850
