Data Plan
Table 18-1 provides the data plan for the OLT, and Table 18-2 provides the data plan for the
ONU.
Table 18-1 Data plan for configuring the EoC broadband service-OLT side
Item Data
VLAN Inband management VLAN: smart VLAN 8
SVLAN: smart VLAN 100 with the attribute Common
SVLAN: smart VLAN 101 with the attribute Common
IP address Inband management IP address: 192.168.50.1/24
GPON service board Port ID: 0/3/1
ONU ID: 1
ONU authentication mode: SN
ONU SN: 48575443E6D8B541
DBA profile Profile name: PrivateLine
Type: type3
Assured bandwidth: 20 Mbit/s
Maximum bandwidth: 50 Mbit/s
ONU line profile Profile ID: 10, bound to the DBA profile named PrivateLine
GEM port IDs: 0, 1, and 2
T-CONT ID: 5
ONU management mode SNMP
Table 18-2 Data plan for configuring the EoC broadband service-ONU side
Item Data
CNU
l CNU ID: 0
l CNU MAC address: 00B0-5240-0003
l CNU SN: hwhw-12341234
l CNU line profile: 1
VLAN Inband management VLAN: smart VLAN 8, adding GPON upstream
port 0/0/0 to this VLAN
HSI SVLAN: smart VLAN 100 with the attribute Stacking, adding
GPON upstream port 0/0/0 to the VLAN
Interactive TV SVLAN: smart VLAN 101 with the attribute Common,
adding GPON upstream port 0/0/0 to the VLAN
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 18 OptiCable EoC Bandwidth Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1861
