l If Control flag is deactive, run the ont activate command in GPON port mode to
activate the ONU.
l If Run state is offline, the ONU fails to be up. The physical line may be broken or the
optical module may be damaged. Check both the materials and line.
l If Config state is failed, the ONU configuration fails. The ONU capability set
outmatches the actual ONU capabilities. Run the display ont failed-configuration
command in diagnosis mode to check the failed configuration item and the failure cause.
Then rectify the fault according to actual conditions.
NOTE
If an ONT supports only four queues, the values of 4–7 of the priority-queue parameter in the gem
add command are invalid. After configuration recovers, Config state will be failed.
6. Configure the management channel from the OLT to the ONU.
NOTE
The management channel needs to be configured only when the OLT remotely manages the ONU using
the SNMP protocol. When the OLT remotely manages the ONU using the OMCI, the management channel
need not be configured.
a. Configure the inband management VLAN and IP address of the OLT.
To remote log in to the ONU and configure the ONU from the OLT, configure the
inband management VLANs and IP addresses of the OLT and the ONU on the OLT.
Create management VLAN 8 and set the inband management IP address to
192.168.50.1/24.
huawei(config)#vlan 8 smart
huawei(config)#port vlan 8 0/19 0
huawei(config)#interface vlanif 8
huawei(config-if-vlanif8)#ip address 192.168.50.1 24
huawei(config-if-vlanif8)#quit
b. Configure the inband management VLAN and IP address of the ONU.
Set the static IP address of the ONU to 192.168.50.2/24 and the management VLAN
ID to 8 (the same as the management VLAN of the OLT).
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#ont ipconfig 1 1 static ip-address
192.168.50.2 mask 255.255.255.0 vlan 8
c. Configure an inband management service port.
Set the management service port ID to 0, management VLAN ID to 8, GEM port ID
to 0, and CVLAN ID to 8. The rate of the inband service port on the OLT is not limited.
Therefore, use traffic profile 6 (default). To limit the rate of the service port, run the
traffic table ip command to add a traffic profile and bind it to the service port.
huawei(config)#service-port 0 vlan 8 gpon 0/3/1 ont 1 gemport 0 multi-
service
user-vlan 8 rx-cttr 6 tx-cttr 6
7. Confirm that the management channel between the OLT and the ONU is available.
l On the OLT, run the ping 192.168.50.2 command to check the connectivity to the ONU.
ICMP ECHO-REPLY packets from the ONU should be received.
l You can remote log in to the ONU from the OLT to perform the configuration.
8. Create a service port.
Configure the port ID of the HSI service to 1, SVLAN ID to 100, GEM port ID to 1, CVLAN
ID to 100, and configure the port ID of the interactive TV service to 2, SVLAN ID to 101,
GEM port ID to 2, CVLAN ID to 101. Rate limitation for upstream and downstream packets
