Item Data Memo
DBA profile Profile name: fttb_dba
Profile type: type3
Assured bandwidth: 8
Mbit/s
Maximum bandwidth: 20
Mbit/s
The ONU is connected to OLT through
the GPON interface.
Line profile Profile name: fttb(c)
Profile ID: 10
T-CONT ID: 4
GEM port ID for
management service: 11
GEM port ID for Internet
access service: 12
GEM port ID for VoIP
service: 13
Network topology
data
PON port: 0/2/1
ONT ID: 1
LAG data plan
LAG Ports: 0/19/0 and 0/19/1
Working mode: LACP
static aggregation
Configure upstream ports 0/19/0 and
0/19/1 into an aggregation group. Each
member port in the aggregation group
allocates packets based on the source
MAC address.
Queue scheduling data plan
Queue scheduling Queue scheduling: strict
priority (SQ) mode
Priority mapping: mapped
into different queues based
on priorities
System default is adopted in this
example.
Management channel data plan
Management VLAN
and management IP
address on the OLT
side
Management VLAN ID: 8
Management VLAN type:
smart VLAN
Inband management IP
address: 192.168.50.1/24
To configure the MDU from the OLT
by logging in to the MDU, the
management VLAN of the OLT and
that of the MDU must be the same, and
the management IP address of the OLT
and that of the MDU must be in the
same network segment.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 19 IPv6 Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1890
