Item Data Memo
Management VLAN
and management IP
address on the ONU
side
Management VLAN ID: 8
Management VLAN type:
smart VLAN
Inband management IP
address: 192.168.50.2/24
Service channel data plan
Internet access
service
OLT VLAN ID:
l CVLAN ID: 256 x
GPON port ID + 32 x
Split ratio x (Splitter
port ID - 1) + ONU port
ID + 1
l SVLAN: VLAN ID 100
and attribute stacking
Upstream VLANs of the
ONU: 1001-1016
Service flow ID: 101
Assume that the split ratio of the optical
splitter is 1:32, the ONU is connected
to port 1 on the optical splitter using the
optical cable, and the user PC is
connected to port 1 on the ONU. In this
case, the inner VLAN is 258 according
to the formula for calculating the inner
VLAN.
For details about the data plan, see
19.3.2 Data Planning.
VoIP service OLT VLAN ID (VLAN
transparently transmitting
the ONU service): 200
ONU VLAN ID: 200
Service flow ID: 201
For details about the data plan, see
19.3.2 Data Planning.
Security data plan
System security Anti-DOS attack: disabled
Anti-ICMP attack: disabled
Anti-IP attack: disabled
System default is adopted in this
example.
User security Anti-MAC duplicate:
disabled
Anti-IP sproofing: disabled
System default is adopted in this
example.
Service security Forward the packet with
PITP tag: enabled
Forward the packet with
DHCPv4 Option82:
enabled
Forward the packet with
DHCPv6 Option18/37:
enabled
In this example, the location
information is added to packets by the
ONU equipment and these packets are
forwarded by the OLT equipment.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
19 IPv6 Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1891
