Huawei SmartAX MA5600T User Manual

Data plan of the ONU side
Item Data Memo
HSI service data plan
Port Upstream port: 0/0/1
Service port: 0/3/1
-
Service VLAN VLAN ID: 1001-1016
VLAN type: smart VLAN
VLAN attribute: common
The ONU supporting 16 FE ports is
used as an example. In actual
configuration, plan the data according
to actual capabilities of devices.
For details about the data plan, see
19.3.2 Data Planning.
Traffic profile Profile ID: 8
Committed rate: 4 Mbit/s
Priority: 0
For details about the data plan, see
19.3.2 Data Planning.
Queue scheduling data plan
Queue scheduling Queue scheduling: strict
priority (SQ) mode
Priority mapping: mapped
into different queues based
on priorities
System default is adopted in this
example.
Service security data plan
System security Anti-DOS attack: disabled
Anti-ICMP attack: disabled
Anti-IP attack: disabled
System default is adopted in this
example.
User security Anti-MAC duplicate:
disabled
Anti-IP sproofing: disabled
System default is adopted in this
example.
PPPoE Service
security
RAIO Type: PITP P
RAIO Mode: common
PITP is recommended for PPPoE.
IPv4oE Service
security
RAIO Type: DHCP Option
82
RAIO Mode: common
DHCPv4 option and DHCPv6 option
are recommended for IPoE.
IPv6oE Service
security
RAIO Type: DHCPv6
Option
RAIO Mode: common
Voice service data plan
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 19 IPv6 Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1892
