NOTE
l The bandwidth type and the attribute of the DBA profile must be compatible with the service to be
carried.
l The system supports five DBA profile types, namely, type1 (fixed bandwidth), type2 (assured
bandwidth), type3 (assured bandwidth+maximum bandwidth), type4 (maximum bandwidth), and type5
(fixed bandwidth+assured bandwidth+maximum bandwidth).
l By default, the system provides DBA profiles 1 to 9, each of which provides typical values for traffic
parameters. By default, T-CONT 0 is bound with DBA profile 1.
l The value of the bandwidth you input when adding the DBA profile rounds down to the nearest integer
multiple of 64. For example, if the input bandwidth value is 1022 kbit/s, the actual bandwidth is 960
kbit/s.
l You can run the display dba-profile command to query the information about the DBA profile.
huawei(config)#dba-profile add profile-id 12 type1 fix 10240
Step 2 Add an ONT line profile.
The ONT line profile ID is 5, T-CONT 1 is bound with DBA profile 12, GEM port 0 is bound
to T-CONT 1, the service type is ETH, and the mapping mode is VLAN mapping.
huawei(config)#ont-lineprofile gpon profile-id 5
huawei(config-gpon-lineprofile-5)#tcont 1 dba-profile-id 12
huawei(config-gpon-lineprofile-5)#gem add 0 eth tcont 1
huawei(config-gpon-lineprofile-5)#gem mapping 0 0 vlan 20
huawei(config-gpon-lineprofile-5)#commit
huawei(config-gpon-lineprofile-5)#quit
Step 3 Add an ONT service profile.
The ONT service profile ID is 10, the quantity of Ethernet ports on the ONT is 4, the quantity
of POTS ports on the ONT is 2, and Ethernet ports 1-4 are added to VLAN 20.
NOTE
The port capability set in the ONT service profile must be the same as the actual ONT capability set.
huawei(config)#ont-srvprofile gpon profile-id 10
huawei(config-gpon-srvprofile-10)#ont-port eth 4 pots 2
huawei(config-gpon-srvprofile-10)#port vlan eth 1-4 20
huawei(config-gpon-srvprofile-10)#commit
huawei(config-gpon-srvprofile-10)#quit
Step 4 Add an ONT.
ONT 0 is connected to GPON port 0, the ONT authentication mode is the SN authentication,
the SN is 323031314D4B2041, the management protocol is OMCI, and ONT line profile 5 and
ONT service profile 10 are bound to ONT 0.
NOTE
You can add an ONT in the following two ways: confirming an auto-discovered ONT and adding an ONT
offline. Here, the method of adding an ONT offline is considered as an example.
You can also run the port ont-auto-find command to enable the function of auto-discovering an ONT,
and then run the ont confirm command to confirm the auto-discovered ONT.
huawei(config)#interface gpon 0/2
huawei(config-if-gpon-0/2)#ont add 0 0 sn-auth 323031314D4B2041 omci ont-
lineprofile-id 5 ont-srvprofile-id 10
huawei(config-if-gpon-0/2)#quit
Step 5 Save the data.
huawei(config)#save
----End
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
181
