Huawei SmartAX MA5600T User Manual

Table 1-7 Mapping between S6-1 to S6-5 and sub-node IDs
S6-5 S6-4 S6-3 S6-2 S6-1 Address
Value of Sub-
nodes
0 0 0 0 0 00000 ( 0 )
0 0 0 0 1 00001(1)
0 0 0 1 0 00010(2)
0 0 0 1 1 00011(3)
0 0 1 0 0 00100(4)
0 0 1 0 1 00101(5)
0 0 1 1 0 00110(6)
0 0 1 1 1 00111(7)
0 1 0 0 0 01000(8)
0 1 0 0 1 01001(9)
0 1 0 1 0 01010(10)
0 1 0 1 1 01011(11)
0 1 1 0 0 01100(12)
0 1 1 0 1 01101(13)
0 1 1 1 0 01110(14)
0 1 1 1 1 01111(15)
(default)
1 0 0 0 0 10000(16)
1 0 0 0 1 10001(17)
1 0 0 1 0 10010(18)
1 0 0 1 1 10011(19)
1 0 1 0 0 10100(20)
1 0 1 0 1 10101(21)
1 0 1 1 0 10110(22)
1 0 1 1 1 10111(23)
1 1 0 0 0 11000(24)
1 1 0 0 1 11001(25)
1 1 0 1 0 11010(26)
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
