l The MG interface and the system parameters must be configured. For the related operations,
see Configuring an SIP Interface and (Optional) Configuring the System Parameters. The
MG interface must be in the normal state.
l The system must be configured with the ISDN service board, that is, the DSRD board or
the DSRE board .
Networking
Figure 3-16 shows an example network of the P2MP ISDN BRA service.
Figure 3-16 Example network of the P2MP ISDN BRA service
Data Plan
Table 3-10 provides the data plan for configuring the P2MP ISDN BRA service.
Table 3-10 Data plan for the P2MP ISDN BRA service
Item Data
MG interface ID 0
ISDN BRA port Subrack ID/Slot
ID/Port ID
0/3/1
Working mode P2MP
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
339
