Huawei SmartAX MA5600T User Manual

huawei(config-if-gpon-0/18)#tcont bind-profile 1 0 1 profile-id 10
8. Divide the ONT port VLAN.
huawei(config-if-gpon-0/18)#ont port vlan 1 0 eth 10 0
huawei(config-if-gpon-0/18)#ont port native-vlan 1 0 eth 0 vlan 1530
9. Configure the GEM port.
huawei(config-if-gpon-0/18)#gemport add 1 gemportid 150 eth
10. Bind the GEM port to an ONT T-CONT.
NOTE
In the actual application, if the ONT terminal does not support the priority queue scheduling, you can use
the CAR to limit the rate when binding the GEM port to the ONT T-CONT.
huawei(config-if-gpon-0/18)#ont gemport bind 1 0 150 1 priority-queue 3
11. Create the mapping between the GEM port and the service stream.
huawei(config-if-gpon-0/18)#ont gemport mapping 1 0 150 vlan 1530
huawei(config-if-gpon-0/18)#quit
12. Add the service port.
huawei(config)#service-port vlan 1530 gpon 0/18/0 gemport 150 multi-service
user-vlan 10 rx-cttr 5 tx-cttr 8
Step 11 Configure the subtending multicast service.
1. Configure the multicast service.
l Configure the native VLAN.
huawei(config)#interface giu 0/19
huawei(config-if-giu-0/19)#native-vlan 0 vlan 100
huawei(config-if-giu-0/19)#native-vlan 1 vlan 100
huawei(config-if-giu-0/19)#quit
l Enable the multicast proxy.
huawei(config)#multicast-vlan 100
huawei(config-mvlan100)#igmp mode proxy
Are you sure to change IGMP mode?(y/n)[n]:y
l Configure the program library.
huawei(config-mvlan100)#igmp program add name program1 ip 224.1.1.1
sourceip 10.10.10.10
huawei(config-mvlan100)#igmp program add name program2 ip 224.1.1.2
sourceip 10.10.10.10
huawei(config-mvlan100)#igmp program add name program3 ip 224.1.1.3
sourceip 10.10.10.10
huawei(config-mvlan100)#quit
2. Configure the subtending multicast.
l Specify the subtending ports.
huawei(config)#btv
huawei(config-btv)#igmp cascade-port 0/19/0
huawei(config-btv)#igmp cascade-port 0/19/1
huawei(config-btv)#igmp cascade-port 0/20/0
l Modify the subtending ports.
huawei(config-btv)#igmp cascade-port modify 0/19/0 static enable
huawei(config-btv)#igmp cascade-port modify 0/19/1 static enable
huawei(config-btv)#igmp cascade-port modify 0/20/0 static enable
huawei(config-btv)#quit
Step 12 Save the data.
huawei(config)#save
----End
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
5 Configuration Example of MSTP Subtending Network
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
472
