The MA5600T supports the SHDSL service of multiple encapsulation modes, such as IPoA,
PPPoA, IPoE, and PPPoE. This topic uses the PPPoE mode as an example to describe how to
configure the SHDSL service. For other encapsulation modes, see "3.1 Example: Configuring
the xDSL Internet Access Service."
1. Configure the SHDSL line profile.
To configure the SHDSL line profile, run the shdsl line-profile add or shdsl line-profile
quickadd command.
huawei(config)#shdsl line-profile quickadd 10 line two-wire rate 2048 2048
psd
symmetric transmission Annex-A remote disable probe disable snr-margin ds-curr
10 ds-worst
10 us-curr 10 us-worst 10 bitmap 0x03
2. Configure the SHDSL alarm profile.
To configure the SHDSL alarm profile, run the shdsl alarm-profile add command.
In this example, the default profile (profile 1) is used.
3. Configure the SHDSL traffic profile.
To configure the SHDSL traffic profile, run the traffic table ip command.
In this example, the default profile (profile 6) is used.
4. Activate the SHDSL port.
huawei(config)#interface shl 0/5
huawei(config-if-shdsl-0/5)#deactivate all
huawei(config-if-shdsl-0/5)#alarm-config all 1
huawei(config-if-shdsl-0/5)#activate all 10
huawei(config-if-shdsl-0/5)#quit
5. Configure the upstream port.
The SHDSL users of MA5600T-2 use the PPPoE authentication. In this case, the smart
VLAN is used to identify the users.
huawei(config)#vlan 3020 smart
huawei(config)#port vlan 3020 0/19 0-1
It will take several minutes, and console may be timeout, please use
command
idle-timeout to set time
limit
Are you sure to add standard port(s)? (y/n)[n]:y
6. Add the service port.
l Ports 0-15 of in slot 0/5 provide the SHDSL service.
l To add service ports in batches, run the multi-service-port command.
huawei(config)#multi-service-port vlan 3020 port 0/5 0-15 vpi 0 vci 35 user-
encap
pppoe rx-cttr 6 tx-cttr 6
Step 9 Configure the POTS service.
1. Configure the upstream ports of the media stream and the signaling flow.
huawei(config)#vlan 1600 smart
huawei(config)#interface vlanif 1600
huawei(config)#port vlan 1600 0/19 0
huawei(config-if-vlanif1600)#ip address 10.176.6.33 24
2. Configure the static route destined to the MGC.
NOTE
When the MGC and the MG are in the same network segment, you do not need to configure the static
route.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
7 Example: Subtending Networking
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
525
