c. Click . The configuration takes effect.
4. Configure parameters of the H.248-based voice users.
a. In the navigation tree, choose Voice > VoIP Basic Configuration.
b. In the right pane, configure the parameters of voice user 1 as follows:
– Line Name: A0
– Associated POTS: 1 (binding port TEL1 on the ONU)
– Select Enable Line Name to enable the voice user configuration.
c. Click . The configuration takes effect.
d. In the right pane, click New to add voice user 2, and configure the parameters of
voice user 2 as follows:
– Line Name: A1
– Associated POTS: 2 (binding port TEL2 on the ONU)
– Select Enable Line Name to enable the voice user configuration.
e. Click . The configuration takes effect.
NOTE
l The terminal IDs A0 and A1 must be consistent with the corresponding configuration on the
MGC.
l If Associated POTS is 1, port TEL1 on the ONU is bound. If Associated POTS is 2, port TEL2
on the ONU is bound.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
763
