2. Configure an ONU line profile.
Create a GPON ONU line profile, named fttd, and bind it to the DBA profile fttd_dba.
huawei(config)#ont-lineprofile gpon profile-name fttd
huawei(config-gpon-lineprofile-1)#tcont 4 dba-profile-name fttd_dba
Create different GEM ports according to different service types, in which
l GEM port 11 is used to carry management services.
l GEM port 12 is used to carry voice services.
l GEM port 13 is used to carry video services.
l GEM port 14 is used to carry Internet access services.
huawei(config-gpon-lineprofile-1)#gem add 11 eth tcont 4
huawei(config-gpon-lineprofile-1)#gem add 12 eth tcont 4
huawei(config-gpon-lineprofile-1)#gem add 13 eth tcont 4
huawei(config-gpon-lineprofile-1)#gem add 14 eth tcont 4
NOTE
1. To change the default QoS mode, run the qos-mode command to set the QoS mode to gem-car or
flow-car, and run the gem add command to set the index of the traffic profile bound to the GEM port.
2. When the QoS mode is priority-queue (PQ), the default queue priority is 0; when the QoS mode is
flow-car or gem-car, traffic profile 6 is bound to the GEM port by default (no rate limitation).
After the configurations are complete, run the commit command to apply the parameter
settings.
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
3. Configure an ONU service profile.
Create a GPON ONU service profile, named fttd. Configure the capability set of the VDSL2
port and POTS port to 1 and 2. Then the system automatically adapts to the ONU according
to the actual capability of the online ONU.
huawei(config)#ont-srvprofile gpon profile-name fttd
huawei(config-gpon-srvprofile-1)#ont-port vdsl 1
After the configurations are complete, run the commit command to apply the parameter
settings.
huawei(config-gpon-srvprofile-1)#commit
huawei(config-gpon-srvprofile-1)#quit
4. (Optional) Add an alarm profile.
l The default GPON alarm profile 1 is used. The alarm thresholds of the default alarm
profile are 0, which indicates that no alarm is generated.
l In this example, the default alarm profile is used, and therefore the configuration of the
alarm profile is not required.
l Run the gpon alarm-profile add command to configure a GPON alarm profile, which
is used for monitoring the performance of an activated ONU line.
Step 2 Add an ONU.
Connect one ONU to GPON port 0/1/0. Set the ONU ID to 1, password to 0100000001, discovery
mode for password authentication to once-on, and management mode to OMCI. Bind the ONU
to ONU line profile fttd and ONU service profile fttd.
There are two methods of adding an ONU: add an ONU offline and confirm an automatically
discovered ONU.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
790
