10.2 Hydraulic lid
The hydraulic lid can be operated by a hydraulic hand valve and the two-hand selector switch
or by an electric push-button and the button for two-hand operation.
Operation via two-hand selector switch and hand valve
When operating the machine, the hydraulic lid can be opened and closed by means of a hand
valve and the two-hand selector switch.
The hand valve must be pushed upward to open the lid. If the hand valve is pressed down, the
lid can be closed. The two-hand selector switch must be pressed as long as the hand valve is
actuated.
As soon as the hand valve or the selector button is released, the lid stops and stays in the
reached position.
